Chapter 2 Installation Instructions
23
865G/GV/PE7MC User Manual
BIOS-Protection Jumper: TBL_EN
If the jumper
TBL_EN i
s
set as Lock
(Pin1 & Pin2),
the system BIOS is protected from being attacked by
a serious
virus, such as the CIH virus. Y
ou will be
unable to flash the BIOS to the motherboard
when the
system BIOS is protected.
Flash write
Enabled
(Default)
Flash write
Disabled
TBL_EN
28
30
