Chapter 2 Installation Instructions
8
865G/GV/PE7MC User Manual
Note :
Excessive temperatures will severely damage the CPU and
system. Therefore, you should install CPU cooling fan and make
sure that the cooling fan works normally at
all times in order to
prevent overheating and damaging to the CPU.
Please refer to your
CPU fan user guide to install it properly.
