Fox Intelligent Stepping
► CPU Clock Adjust
This option is used to adjust the CPU clock.
► CPU Multiplier Adjust
This option is used to adjust the CPU Clock Ratio. Multiply CPU clock with this ratio, you can
get the CPU speed. Increase this ratio may overclock your CPU. This option will be valid if
your CPU ratio is unlocked and will be displayed only if your CPU is supporting this feature.
► CPU-NB HT Link Speed
HT stands for HyperTransport bus. The CPU<->NB HT Speed option controls the physical
speed of the CPU to Northbridge HT link. The physical speed of the link is determined by
multiplying the CPU clock with the CPU<->NB HT Speed setting.
► CPU-NB Multiplier Control
This item is used to select CPU-NB Multiplier run as Auto or Manual mode.
Select [Auto] for CPU-NB default speed.
Select [Manual], then CPU-NB speed is manually selected according to the setting of “CPU-
NB Multiplier Adjust”.
► Memory Speed Mode
This item is used to enable/disable provision of DRAM timing by SPD device. The Serial
Presence Detect (SPD) device is a small EEPROM chip, mounted on a memory
module. It contains important information about the module’s speed, size, addressing mode
and various other parameters, so that the motherboard memory controller (chipset) can better
access the memory device.
Select [Auto] for SPD enable mode.
Select [Limit], the DRAM speed will not exceed the specied value listed in the “Memory
Speed Adjust” item. If SPD value is faster than “Memory Speed Adjust” value, it will run at the
specied “Memory Speed Adjust” speed. Otherwise, SPD value is selected.
Select [Manual], then DRAM speed is manually selected according to the set value of “Memory
Speed Adjust”.
► GFX Engine Clock Override
This item allows you to enable/disable GFX Engine Clock Override support.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Fox Intelligent Stepping
CPU Clock Adjust [200] Help Item
CPU Multiplier Adjust [Auto]
Current CPU Speed : 3000MHz
CPU-NB HT Link Speed [Auto]
Current FSB/HTT Speed : 2000MHz
CPU-NB Multiplier Control [Auto]
Current CPU-NB
Speed : 2000MHz
Memory Speed Mode [Auto]
Current DRAM Speed : N/A , 800MHz
GFX Engine Clock Override [Disabled]
PCIE Clock Abjust [100]
Spread Spectrum [Enabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit
F1:General Help F9:Optimized Defaults
200

Foxconn A76GMV Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	4.4 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1
Supported storage drive interfaces	SATA II
Graphics card	Radeon 3000
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
