PC Health Status
► Warning Temperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning beep.
► Shut Down Temperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This function works only when your operating system is supporting ACPI.
► Case Open Warning
This item is used to enable or disable case open warning function.
► CPU Temperature(Tcontrol)/System Temperature
The CPU/System temperature are automatically detected and displayed by the system.
► CPU Fan/System Fan Speed
The CPU fan/System fan speed are automatically detected and displayed by the system.
► CPU Core/DRAM Voltage/HT Voltage/+5.0V/+12.0V
The current voltages are automatically detected and displayed by the system.
► CPU Smart Fan Function / System Smart Fan Function
This option is used to enable or disable smart fan function.
► Start PWM Temperature
It allows you set a temperature value from which smart fan starts its operation.
► Start PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
value and smart fan begins its operation. The higher PWM value can achieve the faster fan
speed.
► Slope PWM Value
The slope controls the PWM value being stepped up or down versus temperature changes.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
PC Health Status
Warning Temperature [Disabled] Help Item
Shut Down Temperature [Disabled]
Case Open Warning [Disabled]
CPU Temperature(Tcontrol) :40
o
C/104
o
F
System Temperature :28
o
C/82
o
F Disabled
CPU Fan Speed :3183 RPM 50
o
C/122
o
F
System Fan Speed :N/A 55
o
C/131
o
F
60
o
C/140
o
F
CPU Core :1.296 V
65
o
C/149
o
F
DRAM Voltage :1.620V 70
o
C/158
o
F
HT Voltage :1.224V
+12.0V :12.229V
+5.0V :4.983V
CPU Smart Fan Function [Enabled]
Start PWM Temperature [035]
Start PWM Value [064]
Slope PWM Value [2 PWM]
System Smart Fan Function [Enabled]
Start PWM Temperature [035]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit
F1:General Help F9:Optimized Defaults
[Disabled]
Options

Foxconn A76GMV Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	4.4 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1
Supported storage drive interfaces	SATA II
Graphics card	Radeon 3000
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
