4-1 RAID Introduction
RAID 0 (Striped)
RAID 0 reads and writes sectors of data interleaved among multiple drives. If any disk member
fails, it affects the entire array. The disk array data capacity is equal to the number of drive mem-
bers times the capacity of the smallest member. RAID 0 does not support fault tolerance.
RAID 1 (Mirror)
RAID 1 writes duplicate data onto a pair of drives and reads both sets of data in parallel. If one
of the mirrored drives suffers a mechanical failure or does not respond, the remaining drive will
continue to function. Due to redundancy, the drive capacity of the array is the capacity of the
smallest drive.
RAID 10 (Striped Mirror)
RAID 10 is a combination of striping and mirroring. This conguration provides optimal speed and
reliability, but you need four SATA hard disks.
RAID 5 (Parity)
RAID 5 provides data striping at the byte level and also stripes error correction information. This
results in excellent performance and good fault tolerance. Level 5 is one of the most popular
implementations of RAID.
RAID Ready
A "RAID Ready" system is a specic system conguration that, with the addition of a second Se-
rial ATA hard drive, can be seamlessly migrated to a conguration that provides either improved
storage performance or data protection from a single hard drive failure.
JBOD (Span)
JBOD stands for “Just a Bunch of Disks”. Each drive is accessed as if it were on a standard SCSI
host bus adapter. This is useful when a single drive conguration is needed, but it offers no speed
improvement or fault tolerance. A spanned volume is a formatted partition which data is stored
on more than one hard disk, yet appears as one volume. Unlike RAID, spanned volumes have
no fault-tolerance, so if any disk fails, the data on the whole volume could be lost. Additionally,
the system or boot partitions cannot be included in a spanned volume. FAT16/32 and NTFS le
systems may be used, and the volume can span up to 32 hard disks.
The nember of hard disks needed in different RAID level:
C
A
U
T
I
O
N
!
RAID Level RAID 0 RAID 1 RAID 10 RAID 5 RAID Ready JBOD
Disk NO. >=2 2 >=4 >=3 >=1 >=1

Foxconn A76GMV Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	4.4 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1
Supported storage drive interfaces	SATA II
Graphics card	Radeon 3000
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
