Internal Graphics Cong
► Internal Graphics Mode
Enable/Disable the integrated UMA graphics controller.
► UMA Frame Buffer Size
Allocates system memory for use as video memory to ensure the most efcient use of
available resources for maximum 2D/3D graphics performance.
This is a memory allocation method addition to the Unied Memory Architecture (UMA)
concept, wherein a static amount of page-locked graphics memory is allocated during driver
initialization. This xed amount of memory will provide the user with a guaranteed graphics
memory at all times, and will no longer be available to the OS.
► Primary Video Controller
This item is used to select which graphics controller is used as the primary boot device.
► Surround View
Surround View is the ATI technology that provides multi-graphics controller display capability
for both the ATI PCIe-based graphics card and the ATI integrated graphics processor (IGP).
Enabling SurroundView does not impact display modes (resolution and color depth) or perfor-
mance. The display mode of each output is controlled independently by the graphics controller
connected to it.
1. When using a non-ATI PCI Express (PCIe) graphics card, Surround View is not supported.
The integrated graphics processor (IGP) is automatically disabled, and the system memory
allocated to the IGP is freed for other use.
2. PCIe graphics card is the default rst display device. Enabling SurroundView in the BIOS
enables the integrated UMA graphics controller, which in turn makes available up to two
additional graphics outputs. When enabling the integrated UMA graphics controller, system
memory will be reallocated.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Internal Graphics Config.
Internal Graphics Configuration
Help Item
Internal Graphics Mode
UMA Frame Buffer Size [128MB]
Primary Video Controller [PCI-GFXO-IGFX] Disabled
Surround View [Disabled]
Enabled
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit
F1:General Help F9:Optimized Defaults
[Enabled]
Options

Foxconn A76GMV Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	4.4 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1
Supported storage drive interfaces	SATA II
Graphics card	Radeon 3000
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
