Foxconn A76GMV User Manual

4
47
Create RAID array
Here we create RAID 0 as an example:
1. Press [2] in the main menu, "Dene LD Menu" appears and the "LD 1" row is highlight, press
[Enter], the scree is shown as below:
2. Press [Space] to select RAID 0.
3. Use [↓] key to highlight the hard disks, change any two of the drives’ "Assignment" status to "Y"
by pressing [Space] or [Y].
4. Press [Ctrl-Y] to save the setting, a message prompts:
5. Press [Ctrl-Y] to clear the RAID array or press any other key to continue, another prompt ap-
pears:
6. Press [Ctrl-Y] to key in the capacity of the RAID array or press any other key to set the array to
its maximum. Then you will see the created array:
[ Dene LD Menu ]
LD No RAID Mode Total Drv
LD 1 RAID 0 2
Stripe Block: 64 KB Fast Init: ON
Gigabyte Boundary: ON Cache Mode: WriteThru
Channel :ID Drive Model Compatibilities Capacity(GB) Assignment
1 :Mas XXXXXXXXXXX SATA XG XX.XX Y
2 :Mas XXXXXXXXXXX SATA XG XX.XX Y
3 :Mas XXXXXXXXXXX SATA XG XX.XX N
4 :Mas XXXXXXXXXXX SATA XG XX.XX N
[↑] Up [↓] Down [ESC] Exit [Space] Change [Crtl-Y] SAVE [PgUp/Dn] Page Change
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
[ Dene LD Menu ]
[ Drives Assignment ]
RAID 0
Fast Initialization Option has been selected
It will erase the MBR data of the disks,
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
Press Ctrl-Y to Modify Array Capacity or press any
other key to use maximum capacity...
[ Dene LD Menu ]
LD No RAID Mode Total Drv Capacity(GB) Status
LD 1 RAID 0
2 163.99 Functional
LD 2 −−−− −−−− −−−−−−−− −−−−
LD 3 −−−− −−−− −−−−−−−− −−−−
LD 4 −−−− −−−− −−−−−−−− −−−−
LD 5 −−−− −−−− −−−−−−−− −−−−
LD 6 −−−− −−−− −−−−−−−− −−−−
LD 7 −−−− −−−− −−−−−−−− −−−−
LD 8 −−−− −−−− −−−−−−−− −−−−
LD 9 −−−− −−−− −−−−−−−− −−−−
LD10 −−−− −−−− −−−−−−−− −−−−
[↑] Up [↓] Down [ESC] Exit [Enter] Select
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
LD 1 RAID 0 2 XX.XX Functional
[ Dene LD Menu ]

Foxconn A76GMV Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
System bus rate	4.4 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II Dual-Core Mobile, AMD Phenom II Quad-Core Mobile, AMD Phenom II Triple-Core Mobile, AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Maximum number of SMP processors	1
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA II connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1
Supported storage drive interfaces	SATA II
Graphics card	Radeon 3000
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
