4. Press <Space> key to select it and press <Enter>, it returns to the main menu. You
can see the 74.5GB disk is ofine, and actions of Recovery change from Contious
Update mode to On-Request.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 5. Acceleration Options
5. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRecovery Recovery(OnReq) N/A 74.5GB
NeedUpdate Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Recovery Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Offline Disk(0)
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
4. Recovery Volume Options

Foxconn H67M Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Memory Type	DDR3
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066
Memory Slots	4
PCIe x1 Slots	2
PCI Slots	1
SATA Ports	4 (SATA II), 2 (SATA III)
Audio	Realtek ALC887 8-Channel HD Audio
LAN	Realtek 8111E Gigabit LAN
Video Ports	1 x HDMI, 1 x DVI, 1 x VGA
USB Ports	10
