5
71
1. Find a PC, put a diskette into its oppy
drive A:, this diskette will be formatted later.
Put the driver CD into DVD-ROM drive.
2. Depending on which platform your system
is, normally, it is a 32-bit XP system. Use
Windows explorer, and go to CD:\Driver\
Intel\RAID\Floppy\32bit, click on Raid-
Tool icon to start the creation.
3. Click "GO" to start.
4. Select the desired destination FDD drive.
It can be the default drive A: or any USB
FDD. Click "OK" to continue.
5. Insert a diskette, click "OK" to continue.
5-1 Create a RAID driver diskette
If you want to install a brand new Windows XP on a AHCI or RAID system, you need to
congure the SATA Mode in BIOS to either AHCI or RAID rst. You also need to create
a RAID driver diskette for use in installing your Windows XP system.
Windows Vista has native RAID driver in itself, you can skip these steps.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Foxconn H67M Series and is the answer not in the manual?

Foxconn H67M Series Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel H67
SocketLGA 1155
Memory TypeDDR3
Maximum Memory32GB
Memory StandardDDR3 1333/1066
Memory Slots4
PCIe x1 Slots2
PCI Slots1
SATA Ports4 (SATA II), 2 (SATA III)
AudioRealtek ALC887 8-Channel HD Audio
LANRealtek 8111E Gigabit LAN
Video Ports1 x HDMI, 1 x DVI, 1 x VGA
USB Ports10
