Foxconn H67M Series User Manual

3
31
Chipset
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
▶ North Bridge
▶ ME Subsystem
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
North Bridge Parameters
Chipset
► North Bridge/ME Subsystem
Press <Enter> to go to its submenu.
North Bridge
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Memory Information
Total Memory 1024 MB (DDR3 1333)
Memory Slot1 0 MB (DDR3 1333)
Memory Slot2 1024 MB (DDR3 1333)
Memory Slot3 0 MB (DDR3 1333)
Memory Slot4 0 MB (DDR3 1333)
VT-d [Disabled]
Initate Graphic Adapter [PEG/IGD]
IGD Memory [64M]
IGD Multi-Monitor [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Low MMIO resources align at
64MB/1024MB
Chipset
► Total Memory
This item displays the current using memory information.
► Memory Slot 1/2/3/4
These items display the memory size installed on each slot.

Foxconn H67M Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Memory Type	DDR3
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066
Memory Slots	4
PCIe x1 Slots	2
PCI Slots	1
SATA Ports	4 (SATA II), 2 (SATA III)
Audio	Realtek ALC887 8-Channel HD Audio
LAN	Realtek 8111E Gigabit LAN
Video Ports	1 x HDMI, 1 x DVI, 1 x VGA
USB Ports	10
