Boot
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Boot
Boot Configuration
Bootup Numlock State [On]
Quiet Boot [Enabled]
CSM16 Module Version 07.63
Boot Option Priorities
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select the keyboard NumLock
state
► Bootup Numlock State
This item is used to select the keyboard numlock state. The defaulte setting is [On].
► Quiet Boot
This item is used to enable/disable the quiet boot.
[Disabled] : Displays the normal POST messages.
[Enabled] : Displays OEM customer logo instead of POST messages.
► Boot Option Priorities
BIOS auto detect the presence of boot devices, you can congure the priority for boot devices.

Foxconn H67M Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
Socket	LGA 1155
Memory Type	DDR3
Maximum Memory	32GB
Memory Standard	DDR3 1333/1066
Memory Slots	4
PCIe x1 Slots	2
PCI Slots	1
SATA Ports	4 (SATA II), 2 (SATA III)
Audio	Realtek ALC887 8-Channel HD Audio
LAN	Realtek 8111E Gigabit LAN
Video Ports	1 x HDMI, 1 x DVI, 1 x VGA
USB Ports	10
