Recovery Volume Options

1. “Recovery Volume Options” is only available when “Recovery” is built. Here, we take

TryRecovery as an example, select “4. Recovery Volume Options” in main menu

and press <Enter>. The screen displays:

2. Use Up or Down key to make a selection to enable Recovery or Master disk.

3. Here, we select “1.Enable Only Recovery Disk“ and press<Enter> to continue. The

screen display:

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

1. Enable Only Recovery Disk

2. Enable Only Master Disk

Enable Only Recovery Disk - enables recovery disk if avaliable and

disables master disk.

Enable Only Master Disk - enables master disk if avaliable and

disables master disk.

Actions will result in change from Contious Update mode to On-Request.

Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032

1. Enable Only Recovery Disk

[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu

[ HELP ]

[ RECOVERY vOLUME OPTIONS ]

Name Level Capacity Status Bootable

TryRecovery Recovery(Cont.) 74.5GB Normal Yes

Select a Recovery volume to do the operation.

[↑↓]-Up/Down [SPACE]-Selects [ENTER]-Done

[ SELECT RECOVERY VOLUME]

TryRecovery Recovery(Cont.) 74.5GB Normal Yes

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

1. Enable Only Recovery Disk

2. Enable Only Master Disk

Enable Only Recovery Disk - enables recovery disk if avaliable and

disables master disk.

Enable Only Master Disk - enables master disk if avaliable and

disables master disk.

Actions will result in change from Contious Update mode to On-Request.

Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032

[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu

[ HELP ]

[ RECOVERY vOLUME OPTIONS ]

1. Enable Only Recovery Disk
