CPU
Support LGA1155 for Intel Sandybridge series CPU
Max processor power up to 95W
Support 32nm CPU
For the latest CPU information,
please visit
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset
Intel®
H67
Memory 4 x 240-pin DDR3 DIMMs
Support up to 32GB of system memory
Dual channel DDR3 1333/1066MHz architecture
Expansion Slots 1 x PCI Express x16 slots
1 x PCI Express x1 slots
2 x PCI slots
Storage H67 chipset:
- 2 x SATA 3.0 connectors 600MB/s data transfer rate
- 4 x SATA 2.0 connectors 300MB/s data transfer rate
- Support RAID 0, 1, 5 and 10
- Support Hot Plug and NCQ (Native Command Queuing )
LAN Realtek 8111E
Audio Realtek ALC887 (H67M-S/H67M)/ALC662 (H67M-V) audio chip:
- High Denition Audio
- 2/4/5.1/7.1-channel (H67M-S/H67M)
- 2/4/5.1-channel(H67M-V)
- Support for S/PDIF Out
- Support Jack-Sensing function
USB
H67 chipset:
- Support up to 12 x USB 2.0 ports (6 rear panel ports, 3 onboard USB
headers supporting 6 extra ports)
NEC chipset:
- Support up to 2 x USB 3.0 ports(H67M-S)
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
6 x SATA connectors
3 x USB 2.0 connectors (supporting 6 x USB devices)
1 x TPM header
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front Panel connector
1 x Front Audio connector
1 x Speaker header (Buzzer connector Reserved)
1 x COM1 connector
1 x SPDIF_OUT connector
1-1 Product Specications

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Foxconn H67M Series and is the answer not in the manual?

Foxconn H67M Series Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel H67
SocketLGA 1155
Memory TypeDDR3
Maximum Memory32GB
Memory StandardDDR3 1333/1066
Memory Slots4
PCIe x1 Slots2
PCI Slots1
SATA Ports4 (SATA II), 2 (SATA III)
AudioRealtek ALC887 8-Channel HD Audio
LANRealtek 8111E Gigabit LAN
Video Ports1 x HDMI, 1 x DVI, 1 x VGA
USB Ports10
