Intergrated Clock Chip Conguration
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Integrated Clock Chip Configuration
ICC OverClocking Lib Version 7.0.0.29
Number of ICC Profiles : 1
Current ICC Profile Index : 0
ICC Enable [Enabled]
ICC Set Clock Enables [Enabled]
Send ICC Lock Registers [Enabled]
Set Profile [Enabled]
Set Profile Index 0
▶ ICC OverClocking
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Integrated Clock Chip
Enabled/Disabled.
Chipset
► ICC Enable
This item is used to enable or disable the Integrated Clock Chip(ICC).
► ICC Set Clock Enables
This item is used to enable or disable the ICC clock.
► Set ICC Lock Registers
This item is used to enable or disable send ICC lock registers.
► Set Profile
This item is used to enable or disable the ICC prole support.
► Set Profile Index
This item appears only when the Set Profile is enabled, it is used to set ICC profile index.
► ICC OverClocking
This submenu is used to display or set ICC clock spread spectrum if the function is supported.
