Foxconn Rattler User Manual

1
3
Internal Connectors 4 x SATA2.0 connectors (Controlled by Intel
®
P67 )
2 x SATA3.0 connectors (Controlled by Intel
®
P67 )
1 x IDE connector (Controlled by Marvel 88SE6121 )
1 x Speaker connector
1 x CD-IN connector
1 x Front Audio connector
2 x SPDIF-OUT connectors
1 x Reset button
1 x Power on button
Back Panel 1 x PS/2 Keyboard port
Connectors 6 x USB 2.0 ports
1 x Clear CMOS button
1 x Optical S/PDIF out connector
1 x Coaxial S/PDIF out connector
1 x 1394a port
2 x LAN ports
2 x USB 3.0 ports
2 x eSATA ports (Only for Rattler)
8-channel Audio ports
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
PCI Express x1 Gen2.0 Support 250MB/s (500MB/s concurrent) bandwidth
Low power consumption and power management features
PCI Express x16 Gen2.0 Support 8GB/s (16GB/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4 (suspend to disk), S5 (soft - off)
Support EuP Function
Bundled Software
AEGIS PANEL
FOX LOGO
FOX DMI
Browser Conguration Utility
Operating System Support for Microsoft® Windows® 7/Vista/XP
Form Factor ATX Form Factor, 12.0 inches x 9.6 inch
es (30.5cm x 24.4cm)
