► SLP_S4 Assertion Stretch Enable
This item is used to enable or disable the SLP-S4 assertion strech.
► SLP-S4 Assertion Width
This item is used to set the SLP_S4 assertion width.
Audio Conguration
► Azalia HD Audio
This item is used to enable or disable the Azalia HD audio.
High Precision Event Timer Conguration
► High Precision Timer
This item is used to enable or disable the high precision timer.
► PCI Express Ports Conguration/ USB Conguration
Press <Enter> to go to its submenu.
PCI Express Ports Conguration
PCI Express Ports Conguration
► PCI Express Port 1/2/3/4/5/6/7/8
These item are used to show the device information in the PCI express ports.
► PCIe Sub Decode
This item is used to enable or disable PCIe sub decode port. This item is available when
subtractive decode agent is enabled.
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
PCI Express Ports Configuration
PCI Express Port 1 [Auto]
PCI Express Port 2 [Auto]
PCI Express Port 3 [Auto]
PCI Express Port 4 [Auto]
PCI Express Port 5 [Auto]
PCI Express Port 6 [Auto]
PCI Express Port 7 [Auto]
PCI Express Port 8 [Auto]
PCIe Sub Decode [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enabled/Disabled the PCI
Express Ports in the chipset.
Chipset

Foxconn Rattler Specifications

General

Brand	Foxconn
Model	Rattler
Category	Motherboard
Language	English
