5-2 BIOS Conguration
1. Enter the BIOS setup by pressing <DEL> key during the POST(Power On Self Test).
2. Use the arrow right/left keys to select the “Advanced” menu, then use the arrow
up/down keys to select the “SATA Conguration” item and press <Enter> to go to the
conguration items.
3. Press <Enter> to select and set the “SATA Mode” option to [RAID Mode].
4. Press <F4> to save the setting then PC will reboot itself.
5-3 Create RAID in BIOS
Enter RAID BIOS Setup
When BIOS is restarted, it will display a message asking you to press <Ctrl>+<I> keys
simultaneously to enter the main menu of Intel
®
Matrix Storage Manager Option ROM
Utility. Press the <Ctrl>+<I> to enter Conguration Utility.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R w6AID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Recover Volume Options
5. Exit
RAID Volume :
None Dened.
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Non-RAID Disk
1
ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Non-RAID Disk
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
SATA Configuration
SATA Mode [RAID Mode]
SATA Port 0 Not Present
Hot Plug [Disabled]
SATA Port 1 Not Present
Hot Plug [Disabled]
SATA Port 2 Not Present
Hot Plug [Disabled]
SATA Port 3 Not Present
Hot Plug [Disabled]
SATA Port 4 Not Present
Hot Plug [Disabled]
SATA Port 5 Not Present
Hot Plug [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
(1) IDE Mode. (2) AHCI Mode
(3) RAID Mode.
Advanced
