DOWNFLOW BRINE
Raw water inlet
Raw/hard water is bypassed during regeneration
Regenerant water to drain
Regenerant solution
being drawn in
Injector feed from
raw water inlet
UPFLOW BRINE
Raw water inlet
Raw/hard water is bypassed during regeneration
Regenerant water to drain
Regenerant solution
being drawn in
Injector feed from
raw water inlet
