Frakco AQUA MAGIC Plus - General Specifications

Page 4
General Specifications
Minimum/Maximum Operating Pressures
20 psi (138 kPa) -125 psi (862 kPa)
Minimum/Maximum Operating
Temperatures
40°F (4°C) – 110°F (43°C)
Power Adapter:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
U.S.
120V
AC
60 Hz
12V AC
500 mA
International
230V AC
50 Hz
12V AC
500 mA
No user-serviceable parts are on the PC board, the motor, or the Power adapter. The means of disconnection from the main
power supply is by unplugging the Power adapter from the wall.
Service flow rate
AM1.5 Valve: 70 gpm (265 lpm, 15.9 m
3
/h) @ 15psig (103kPa)
drop AM2 Valve: 115 gpm (435 lpm, 26.1 m
3
/h) @ 15psig
(103kPa) drop AM2QC Valve: 125 gpm (473 lpm, 28.4 m
3
/h) @
15 psig (103 kPa) drop
Backwash flow rate
AM1.5 Valve: 52 gpm (192 lpm, 11.8m
3
/h) @ 25 psig (172 kPa) drop
AM2 Valve: 80 gpm (303 lpm, 18.2 m
3
/h) @ 25 psig (172 kPa) drop
AM2QC Valve: 85 gpm (322 lpm, 19.3 m
3
/h) @ 25 psig (172 kPa) drop
CV Service
AM1.5 Valve: 18.1
AM2 Valve: 29.7
AM2QC Valve: 32.3
CV Backwash
AM1.5 Valve: 10.4
AM2 Valve: 16.0
AM2QC Valve: 17.0
Meter:
Accuracy
Flow Range
AM1.5 Valve:
± 5 %
0.5 – 75 gpm (1.9 – 283 lpm)
AM2 Valves:
± 5 %
1.5 – 150 gpm (5.7 – 568 lpm)
Regenerant Refill Rate
AM1.5 Valves: 0.5 gpm (1.9 lpm)
AM2 Valves: Variable - Shipped from Factory with 2.2 gpm (8.33 lpm)
Injectors
AM1.5 Valve: See Injector Graphs V3010-15A through 15I
AM2 and AM2QC Valve: See Injector Graphs V3010-2R-15B through 2G
Inlet/ Outlet
AM1.5 Valve: 1.5” Female NPT or BSPT
AM2 and AM2QC Valve: 2” Female NPT or BSPT
Drain Line
AM1.5 Valve: 1.25” Female NPT
AM2 and AM2QC Valve: 1.5” Female NPT
*Distributor Tube
Sizing: AM2QC Valve
AM1.5and AM2
Valve
Female NPT Inlet & Outlet
Female BSPT Inlet & Outlet
2.375” OD (2.0” NPS)
1.90” OD (1.5” NPS)
+2.25” - +2.5”
± 0.5”
63 mm OD
50 mm OD
+57 mm - +64 mm
± 13 mm
Tank Connection AM1.5 and AM2 Valves: 4”-8UN
AM2QC Valve: 4”-8UN, 6” Flange, Side Mount
Shipping Weight
AM1.5 Valve with Meter: 23 lbs. (11 kg)
AM2 Valve with Meter: 30 lbs. (14 kg)
AM2QC Valve with Meter: 30 lbs. (14
kg)
PC Board Memory
Nonvolatile EEPROM (electrically erasable programmable read-only memory)
Compatible with the following typical
concentrations of regenerants/chemicals
Sodium chloride, potassium chloride, potassium permanganate,
sodium bisulfite, chlorine and chloramines
*Height is based off the top of tank. Installer to verify proper engagement and allowance for tank expansion
