11
7. Attach the Right Handrail (83) to the Right
Upright(85)withtwo5/16"x23/4"Screws(12)
andtwo5/16"StarWashers(8).Do not tighten
the Screws yet.
Remove and discard the two indicated screws
(B) from the Right Handrail (83).
7
85
83
B
12
8
6. Identify the Left Handrail (79), which is marked
“Left.” If there is a wire in the Left Handrail,
remove and discard it.
Hold the Left Handrail (79) near the Left Upright
(84). Insert the wire tie on the Upright Wire (91)
into the bottom and out of the end of the Left
Handrail as shown. Then, pull the Upright Wire
through the Left Handrail.
Attach the Left Handrail (79) to the Left Upright
(84)withtwo5/16"x23/4"Screws(12)andtwo
5/16"StarWashers(8).Make sure not to pinch
the Upright Wire (91). Do not tighten the
Screws yet.
Remove and discard the two indicated screws
(B) from the Left Handrail (79).
12
8
79
84
Wire
Tie
91
6
B
