Froilabo BM 3E Essential - Service; Customer Administration Menu; Setting the High and Low Alarms

Original manual – Iss. 0.1 User manual – BM 3E Freezer 24/ 44
6.10 Service / customer administration menu
Description
Command
From the Home screen, access the Servicing menu.
Enter the access code (five digits).
Default code: “11111”.
Confirm.
Servicing menu
Top sensor offset
(protected by servicing password)
Bottom sensor offset
(protected by servicing password)
Door open alarm delay
Low temperature alarm threshold
High temperature alarm threshold
Emergency injection configuration: OFF / CO
2
/ N
2
Emergency injection trigger threshold
Start-up delay time
Return to the main display
6.10.1 Setting the high and low alarms
Description
Command
Servicing menu
Low temperature alarm threshold
Set the desired temperature at which the alarm will be
triggered.
High temperature alarm threshold
Set the desired temperature at which the alarm will be
triggered.
Return to the main display
