6.10.2 Setting the start-up time delay
If several freezers are installed on the same electrical network, the start-up time delay can be used to start the units in
turn in order to avoid momentarily overloading.
Description
Command
Servicing menu
Start-up delay time
Set the delay before the unit starts up.
After the freezer is powered up, the first stage
compressor will start only after this delay has passed.
Note:
This parameter can also be set on the Essential model. This operation must be performed by a qualified technician. It
entails opening the rack and setting switches on the Artic board.
The switches marked “SW1” should be set to allow at least 5 seconds between each start-up. The number set in
binary corresponds to a delay of 30 seconds + the number of seconds encoded in binary.
Description
Command
Artic board
Set the desired value based on the binary codes
shown below.
Switch No.
1
2
3
4
5
6
7
8
Binary total
Time delay
(in seconds)
Binary weight
8
7
6
5
4
3
2
1
Example 1
0
0
0
0
0
0
0
0
0
30 (30+0)
Example 2
0
0
0
0
0
1
0
1
5
35 (30+5)
Example 3
0
0
0
0
1
0
1
0
10
40 (30+10)
Example 4
0
0
0
0
1
1
1
1
15
45 (30+15)
Example 5
0
0
0
1
0
1
0
0
20
50 (30+20)
Example 6
0
0
0
1
1
0
0
1
25
55 (30+25)
etc.
…
…
.
6.11 Setting the CO
2
/ N
2
injection threshold
To use emergency injection, CO
2
/ N
2
injection must be enabled and the injection threshold must be set.
Warning: When the freezer is installed, injection must be enabled only once the temperature setpoint has been
reached, otherwise the gas cylinders will be discharged before the temperature drops for the first time.
Warning: Using these gases is hazardous. Please refer to the safety data sheet in section 13 SAFETY.
