Froling P2-15 - Page 72

Installers and service technicians
Parameter list - Lambdatronic P 3100
Page 72
B0190806 s
7
Air settings ... ←
←←
← ID fan MIN 35% ←
Lower control limit; check during initial setup
Start from 0% and test going up in steps of 5%. . Start
level setting through control parameter, → ID fan start
point
Fan MIN 16% ← Adjustment to fan in use – do not change setting
Fan MAX 65% ←
Fan speed at maximum output
Factory settings: P2-10: 60%, P2-15: 65%, P2-20:
70%, P2-25: 75%
100% output from
Flue gas temp. 100°←
←←
←
If the flue gas temperature is above the specified
target value, fuel output should reach 100% (upper
point of the start ramp)
Output at flue gas temp.
of 20° 50%←
←←
←
Output limit (lower point of the start ramp)
Offset for ID fan 0%←
←←
← The ID fan curve is increased by this value
New induced draft fan Y←
←←
←
ID fan with rubber buffer → Y
ID fan with spacers → N
Pellets feed ... ←
←←
←
Feed MAX 70% ←
Slide-in at maximum output for systems without
lambda probes; systems with lambda probes are
controlled by the O2 regulator.
STBY. Wait 1 10m ← 1. Shutdown pause before the 1st safety slide-in
STBY. Wait 2 20m ← 2. Pause between 1st and 2nd safety slide-in
Shutdown slide-in 1s ←
Duration of safety slide-ins (for status: Shutdown slide-
in 1 and 2)
Ash screw Runtime: 5s←
←←
← Runtime of the ash screw
Ash screw Cycle: 1200←
←←
←
Ash screw cycle; control of the ash screw depending on
the pellet slide-in.
EOS runtime 20s←
←←
← Runtime of heat exchanger cleaning
Outfeed ... ←
←←
←
1. Start time for
automatic filling 15:00←
←←
←
1. Start time for filling. This is only carried out if the fill
level in the container is under 85%.
Only with suction
discharge unit!
2. Start time for
automatic filling 15:00←
←←
←
2. Start time for filling. This is also only carried out if
the fill level in the container is under 85%.
Period of screw
cycle 30s←
←←
←
Discharge screw runtime, minus a pause of 10* sec.
(*Pause time = “Suction unit pre-activation time”)
Preliminary suction 10s ← Time before the discharge screw starts
ID fan after shut down 15s ←
Time after discharge screw stops.
For sucking the hose clear.
Fill cyclone below: 35% ←
Minimum level of day store  suction cycle starts when
the level falls below this value.
Note: with underground tanks or bag silos the values
for pre-activation and post-shutdown times should be
set according to the manufacturer’s instructions.
