Installers and service technicians
Parameter list - Lambdatronic P 3100
Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestraße 12, A-4710 Grieskirchen, Austria Page 73
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com
B0190806
1. Start time for
automatic filling 15:00←
←←
←
1. Start time for filling. This is only carried out if the fill
level in the container is under 85%.
Only for universal
suction systems
2. Start time for
automatic filling 15:00←
←←
←
2. Start time for filling. This is also only carried out if
the fill level in the container is under 85%.
Fill cyclone below: 35%
←
Minimum level of day store suction cycle starts when
the level falls below this value.
Boiler times ... ←
←←
←
Start 1. Storage
tank load 05:00←
←←
←
Only effective in
transitional
operation!
End 1. Storage
tank load 10:00←
←←
←
Start 2. Storage
tank load 17:00←
←←
←
Start 2. Storage
tank load 22:00←
←←
←
For systems with storage tank in transitional
operation:
The boiler is switched on if the temperature falls
below the “Store up. min. temp.” during these time
windows.
Note: Ideally set start 00:00 to end 24:00
Start 1. heating
period 05:00←
←←
←
End 1. heating
period 08:00←
←←
←
Start 2. heating
period 17:00←
←←
←
End 2. heating
period 21:00←
←←
←
For systems without storage tank in transitional
operation!
The boiler is activated within these time windows.
CAUTION!
DHW tank loading times must be within the time
window of the boiler times.
Start EOS 1 08:00←
←←
←
Start time 1 for heat exchanger cleaning. The boiler
must have operated for at least 2 hours since the last
cleaning.
Start EOS 2 15:00←
←←
←
Start time 2 for heat exchanger cleaning. The boiler
must have operated for at least 2 hours since the last
cleaning.
Only with Lambda control:
Lambda values...
Residual O2
content target 9.0%←
←←
←
Target value for residual oxygen content.
Residual O2
shut down 19.0%←
←←
←
If the residual oxygen content in heating status goes
above this specified value, after the safety time, the
boiler goes to “Fault” status, error message: “Safety
time O2 too high” see chapter 6 Troubleshooting
No feed below: O2 4.5%←
←←
← No pellets are slid in below this oxygen value.
O2 control max 130%
←
Specific settings for O2 controller – do not change
Factor for O2 controller 1.50
←
Specific settings for O2 controller – do not change
Control par. ...
←
Start level draft fan 0.0%
←
Start level for ID fan; to correct the direct control curve
of the induced draught fan.
Specific setting for ID fan – do not change
