6.3 Feeding the strap around the
package
• The strapping is fed around the package as
illustrated.
Warning! The plastic strap which will be welded
must be free from oil, grease and other dirt.
Dirty plastic straps can't be welded correct!
6.4 Inserting the strap
• Pull up the handle lever firmly with your right
hand.
• Insert the two straps well aligned on each other
into the strap guide using your left hand.
The lower strap end must slightly protrude the
end of the base plate.
• Release the handle lever.
6.5 Tensioning the strap,
Operation mode Manual
• Press down the tension button and then
release it again after the desired strap tension
has been reached.
The tensioning operation can be interrupted and
restarted at any time.
During tensioning the LED lights green.
After automatic cut off of the tensioning force
it can be tensioned again not before
8 seconds.
