3 TECHNICAL DATA
Description of the tool
The tool model P331 has been designed to strap packages with plastic strapping. The plastic strapping is fed
around the package manually or in combination with a strap feeder. The straps are inserted in the tool,
tensioned, sealed by friction welding and separated from the strap coil.
Tool size with battery
Length: 396 mm / 15.6"
Width: 166 mm / 6.5"
Height: 175 mm / 6.9"
Weight
with battery: 6.4 kg / 14.1 lbs
Noise information
The A-weighted equivalent continuous sound level at the work place of the machine operator is
typical 82 dB (A). The sound power level is 90 dB (A).
Deviation K: 3 dB
These values were determined according to EN ISO 11204 / EN ISO 3744.
Wear ear protection!
Vibration information
The weighted effective value of the acceleration typically amounts to less than 2.5 m/s
2
.
This value was determined according to DIN EN 60745-1 (12.2003).
Deviation K: 0.6 m/s
2
Strap material
Strap qualities: PET (Polyester) plain or embossed.
The plastic strap must be according to DIN EN 13394.
Use only plastic straps recommended by your sales shop (name and address
on the rear of the operation manual).
Strap dimensions: 19.0 - 32.0 mm x 0.60 - 1.53 mm (see chart of types).
Use only plastic straps with the correct strap dimensions for your tool.
Operation mode
Manual or Semi-Automatic mode
Strap tension
Tensioning force*: Adjustable from 1200 - max. 7000 N / 270 - max. 1575 lbs.
Tensioning speed*: approx. 39 - 63 mm/s / 1.5 - 2.5 inch/sec.
Seal
Type of seal: Friction weld sealing
Strength of seal*: approx. 75% of the tensile strength of the plastic strap.
* The value depends on the strap quality.
