Fromm P331 M/HA - Page 25

[ ] = Group * = Wearing parts
25
43028601.een.fm
[P33.0204] P33.0212 1 GEAR WHEEL B18
[P33.0205] P33.0208 1 GEARING COVER C15
[P33.0206] P33.0208 1 LEVER C16
[P33.0207] P33.0208 1 GEAR BODY B17
[P33.0208] P33.0212 1 GEAR B14+
[P33.0209] P33.0212 1 CONICAL GEAR WHEEL D23
[P33.0210] P33.0212 1 GEAR WHEEL C22
P33.0211
*
P33.0212 1 MOTOR D22
[P33.0212] 1 BASE MODEL D6+
P33.1236 1 GUIDE PIN D12
P33.1237 1 GUIDE PIN D12
P33.2102 P33.0201 1 BODY D7
P33.2103 P33.0201 1 BOLT A18
P33.2104 P33.0202 1 PINION A15
P33.2105 P33.0203 1 SPRING BOLT B8
P33.2106 P33.0203 1 SPRING SLIDE A8
P33.2107 P33.0212 1 RETAINER A23
P33.2108 P33.0205 1 GEARING COVER D15
P33.2109 P33.0207 1 GEAR BODY B16
[P33.2111] P33.0212 1 MOTOR HOUSING A22
[P33.2113] P33.0212 1 MOTOR HOUSING B19
P33.2115 P33.2116 1 TURNING BUTTON C20
[P33.2116] P33.0212 1 CIRCUIT BOARD 36V B21
P33.2117 P33.0212 1 HANDLE LEVER B21
P33.2118 P33.0212 1 TOUCH CONTACT-SWITCH A21
P33.2122 P33.0209 1 CONICAL GEAR WHEEL D23
P33.2123 P33.0210 1 GEAR WHEEL C21
P33.2124 P33.0212 1 CONICAL GEAR WHEEL C22
P33.2130 P33.0212 1 ECCENTRIC SHAFT C9
P33.2131 P33.0212 1 GEAR WHEEL A23
P33.2132 P33.0212 1 COVER B9
P33.2133 P33.0212 1 PUSHER B14
P33.2135 P33.0212 1 INSERTATION PART A20
P33.2136 P33.0212 1 COVER A20
P33.2137 P33.0212 1 HANDLE SHAFT C19
P33.2142 1 CENTERING SLEEVE C12
P33.2143 1 COVER A4
P33.2145 P33.0212 1 DISK B22
P33.2149 1 STRAP GUIDE D4
P33.2155 P33.0212 1 DOWEL C22
P33.2229
*
1 TENSIONING WHEEL C4
[P35.0202] P33.0212 1 ROCKER A15
[P35.0213] P33.0208 1 GEAR WHEEL B15
[P35.0214] P33.0208 1 WHEEL C13
[P35.0217] P33.0208 1 RATCHET WHEEL C17
[P35.0218] P33.0208 1 GEAR WHEEL D16
[P35.0226] 1 END COVER D4
[P35.0227] 1 PUSHER B12
P35.4103 1 STEEL INSERT D9
P35.4104
*
1 WELDING STOP GRIPPER D9
P35.4105 1 STRAP GUIDE PLATE A3
P35.4106 P35.0202 1 ROCKER A16
P35.4107
*
P33.0212 1 WELDING GRIPPER D10
43.0286.01 P331/25/1.20-1.35/7.0 P331.0001.01 17.06.14
Item-No. in group Pcs. Description Dimension Field
