Permitted cables
for the data com-
munication area
Cables with the following design can be connected to the terminals of the inverter:
- Copper: round, solid
- Copper: round, fine-stranded
IMPORTANT!
Connect the individual conductors to an appropriate ferrule if several individual conduct-
ors are connected to one input of the push-in terminals.
WSD connections with push-in terminal
Dis-
tance
max.
Stripping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable recom-
mendation
100 m
109 yd
10 mm
0.39 inch
0.14-1.5 mm
2
AWG 26-16
0.14-1.5 mm
2
AWG 26-16
0.14-1 mm
2
AWG 26-18
0.14-1.5 mm
2
AWG 26-16
min. CAT 5
UTP (unshiel-
ded twisted
pair)
Modbus connections with push-in terminal
Dis-
tance
max.
Stripping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable recom-
mendation
300 m
328 yd
10 mm
0.39 inch
0.14-1.5 mm
2
AWG 26-16
0.14-1.5 mm
2
AWG 26-16
0.14-1 mm
2
AWG 26-18
0.14-1.5 mm
2
AWG 26-16
min. CAT 5
STP (shielded
twisted pair)
IO connections with push-in terminal
Dis-
tance
max.
Stripping
length
Solid
Fine-stran-
ded
Fine-stran-
ded with fer-
rules with
collar
Fine-stran-
ded with fer-
rules without
collar
Cable recom-
mendation
30 m
32 yd
10 mm
0.39 inch
0.14-1.5 mm
2
AWG 26-16
0.14-1.5 mm
2
AWG 26-16
0.14-1 mm
2
AWG 26-18
0.14-1.5 mm
2
AWG 26-16
Single con-
ductor pos-
sible
LAN connections
Fronius recommends using at least CAT 5 STP (shielded twisted pair) cables and a maximum distance of
100 m (109 yd).
Cross section of
the AC cable
For a standard M32 metric screw joint with a reducer:
Cable diameter from 7-15 mm
When using an M32 metric screw joint (reducer removed):
cable diameter from 11-21 mm
(with a cable diameter of less than 11 mm, the strain-relief force is reduced from 100 N to
a maximum of 80 N)
