system and/or a Fronius Ohmpilot installed for communication between the indi-
vidual components. The installation is carried out on an indoor DIN rail with cor-
responding back-up fuses, which are adapted to the cable cross-sections of the
copper conductors and to the maximum current of the meter. The Fronius Smart
Meter TS must only be operated in accordance with the specifications in the en-
closed documentation and in accordance with local laws, regulations, provisions,
standards and within the limits of technical possibilities. Any use of the product
other than as described in the intended use shall be deemed to be not in accord-
ance with the intended purpose. The available documentation forms part of the
product and must be read, observed and kept in good condition. It must also be
accessible at all times at the place of installation. The available documents do
not replace regional, state, provincial or national laws, or regulations or stand-
ards that apply to the installation, electrical safety and use of the product. Froni-
us International GmbH assumes no responsibility for compliance with or non-
compliance with these laws or regulations in connection with the installation of
the product.
Interventions on the Fronius Smart Meter TS, e.g. modifications and alterations,
are not permitted. Unauthorised interventions will void the warranty and war-
ranty claims and, as a rule, void the user's authority to operate the equipment.
The manufacturer shall not be liable for any damage resulting from such use.
Reasonably foreseeable misuse:
The Fronius Smart Meter TS is not suitable for the supply of life-sustaining med-
ical devices or for the billing of subtenants.
Scope of supply
(1) 2x seal wire
(2) 2x connection cover
(3) Fronius Smart Meter TS 5kA-3
(4) Quick Start guide
Positioning The Fronius Smart Meter TS can be installed in the following positions in the sys-
tem:
Positioning at the feed-in point:
13
