MAINTENANCE
OM 0408SB1174-A
35
MAINTENANCE
Shearbolts
Check the shearbolts indicated on the figure
below at frequent intervals for proper tightness to
be sure the blower is in safe working condition.
Figure 33: To access the shear bolts, pull up the
access pannel (item 1) located near the chain. If
the shearbolts need replacement, use the
following parts only:
Drive shaft
:
Shearbolt hex. 1/4" NC x 1 1/4" gr.2, incl. nut.
Part # 5RD669345.
Driveline
:
Shearbolt M8 x 1.25 x 50mm gr. 6.6 and nut.
Part # 5RD4700060.
WARNING
Provide adequate blocking before working
under the snowblower when in the raised
position.
Driveline
IMPORTANT: When the snowblower is not
used for more than two weeks, perform
driveline maintenance and always store it in a
dry place, away from bad weather conditions.
SHEAR BOLT
ACCESS
Figure 33
