Frontier SB1174 - 5 RDF0047 - Hydraulic Rotation

PARTS
OM 0408SB1174-A
47
5RDF0047 - HYDRAULIC ROTATION
R
EF. DESCRIPTION QTY PART #
1 Hydraulic motor 50cc 1 5RD3910092
- Seal Kit 1 5RD3910093
2 Key 1/4" x 1" woodruff (incl. in 5RD3910092) 1 5RD659191
3 Motor gear 1 5RD669705
4 Flow restrictor 0.052" 2 5RD664362
5 Rubber hose 1/4" x 75"lg. 2 5RD664920
6 Reducer 1/4"NPT female x 1/2" NPT male 2 5RD2600223
7 Male quick coupler 2 5RD656480
8 Dust cap 2 5RD664898
9 Flat washer 1/4" (5/16" hole) PTD 1 5RD1400002
10 Lockwasher 1/4" PTD 3 5RD1200002
11 Gear shield 1 5RD669715
12 Bolt hex. 1/4"NC x 3/4" PTD 3 5RD0100003
13 Bolt hex. 3/8"NC x 1" PTD 4 5RD0100038
14 Lockwasher 3/8" PTD 4 5RD1200004
15 Flat washer 3/8" (7/16" hole) PTD 4 5RD1400004
16 Motor spacer 1 5RD669718
17 Nut hex. 1/4"NC PTD 2 5RD0900001
18 Hose clamp 1 5RD666583
19 Nylon insert locknut 3/8"NC PTD 1 5RD1000006
20 Bolt hex. 3/8"NC x 1 1/2" PTD 1 5RD0100040
21 Tie wrap 1/4" x 15" lg. 2 5RD 2100009
