2-3
2.2 Cabinetry (cont.)
ITEM PART # COMPONENT
106-9311 Cabinet Assembly
1 106-9431 Upright Assembly, LT Enclosure
2 106-9432 Upright Assembly, RT Enclosure
3 824-1920 Bridge Weldment, Pump/Motor
4 232-4568 Side, RT, Cabinet
5 231-4568 Side, LT, Cabinet
6 220-4316 Back Panel, Upper
7 220-4317 Back Panel, Lower
8 230-4318 Basket Hanger, Wingstreet
9 823-6716 Tilt Housing Single Station
10 823-5440 Cove, Element Tilt Housing
11 106-9243 Top Cap
12 220-4328 Heat Shield, Top Cap
13 230-4332 Bezel, One-Controller
14 106-9346 Frame, Control Panel
106-9242 Door Assembly
15 810-0275 Spring, Door Pin
16 106-4067 Pin Assembly, Door
17 810-1105 Magnet, Door
18 230-4960 Handle, Eurolook Door
19 812-1326 Caster, Adjustable with brake
20 810-3010 Legs, Optional
