Frymaster 8196428 - Contactor Boxes

2-8
2.4.4 Contactor Box
ITEM PART # COMPONENT
1 106-6031 Harness Assembly, Contactor Box Control, 12 Pin
2 106-6799 Harness Assembly, 208/240V Contactor Box Power
3 220-4489 Plate, Contactor Box Cordset Cover
4 220-1331 Plate, Power Cord Cover
5 807-2284 Heat Contactor, 50 Amp Mechanical, 24V Coil
6 807-3970 Block, 3 Pole, 600V, 175 Amp Terminal
7 810-1202 Latch Contactor, 3 Pole, 600V, 40 Amp
8 807-0070 Ground Lug Terminal
* 106-8744 Harness Assembly, MDI Contactor Box, 6 Pin (below Item 5)
* 106-8745 Harness Assembly, MDI Contactor Box, 9 Pin (below Item 5)
* 807-4658 Cordset, 4GA, 3 Phase, 4 Wire with Plug with Strain Relief
* Not illustrated.
