Frymaster Dean Super Runner Series - Fryer Wiring Diagrams and Schematics

1-14
1.8 Wiring Diagrams
1.8.1 Current Production Units with Honeywell Gas Valve (Non-CE)
HONEYWELL 1/2 P.S.I.
1/2 P.S.I.
HONEYWELL
OFF
ON
PILOT
C
HONEYWELL
1/2 P.S.I.
ADJ.
PILOT
17C
17C
12C
PILOT
GENERATOR
HIGH-LIMIT
THERMOSTAT
SAFTY DRAIN
SWITCH
(OPTIONAL)
IN-LINE
SPLICE
ON/OFF
SWITCH
(OPTIONAL)
FENWALL
OPERATING
THERMOSTAT
IN-LINE
SPLICE
8050438D
OPERATING
THERMOSTAT
1C
2C
PP
PP
TH
TH
Combination Gas
Valve
High-Limit
Operating Thermostat
White
Red
Black
Red
Red
Black
Thermopile
TH
TH
PP
PP
Old Style Honeywell Millivolt Gas Valve Wiring (Non-CE)
