Frymaster Dean Super Runner Series - Single Under Fryer Filter (SUFF) Parts

FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-30
2.9 Single Under Fryer Filter (SUFF) Components
2.9.1 SM50 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1062257SP Filter Pan Assembly SUFF 50
1 8233796 Filter Pan, SUFF 50
* 8130684 Plug, Hex Socket, ⅜" NPT
* 8130679 Plug, ⅛" S/S Square Head (Female Disconnect)
2 8233790 Support Grid (Bottom Pan Screen)
3 8030317 Paper, Filter- 8-¼" x 25-¾"
4 8233795 Hold-down Ring, Weighted
5 8233736 Crumb Basket
6 8233797 Filter Pan Cover, Front
7 8233798 Filter Pan Cover, Back
8 8090428 Bolt, ¼" -20 x ½" Steel
9 8234794 Insert, Caster
10 8090820 Nut, Oval Locking- ¼" -20
11 8090805 Screw, ¼" -20 x ½"
12 8102805 Caster, 2"
* Not Illustrated
