Frymaster Dean Super Runner Series - SM60 and SM80 Series Fryers

FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-31
2.9.2 SM60 and SM80 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1 8233774 Filter Pan, SUFF 60 (Use 1062228SP for Assembly)
* 8233821 Filter Pan, SUFF 80 (Use 1062381SP for Assembly)
* 8130684 Plug, Hex Socket, ⅜" NPT
* 8130679 Plug, ⅛" S/S Square Head (Female Disconnect)
2 8233768 Support Grid (Bottom Pan Screen) SUFF 60/80
3 8030289 Paper, Filter- 22" x 34" - SUFF 60/80
4 8233768 Hold-down Ring, Weighted- SUFF 60
* 8233849 Hold-down Ring, Weighted- SUFF 80
5 8233736 Crumb Basket- SUFF 60/80
6 8233766 Filter Pan Cover, Front- SUFF 60
* 8233739 Filter Pan Cover, Front- SUFF 80
7 8233767 Filter Pan Cover, Back- SUFF 60
* 8233741 Filter Pan Cover, Back- SUFF 80
8 8090428 Bolt, ¼" -20 x ½" Steel
9 8234794 Insert, Caster
10 8090820 Nut, Oval Locking- ¼"-20
11 8090805 Screw, ¼" -20 x ½"
12 8102805 Caster, 2"
* Not Illustrated
