FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-17
2.5.1 Oil Drain Manifold, Drain Flush and Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 8233565 Elbow, with Bracket (LH)- 1-¼"- UFF 50
* 8233566 Elbow, with Bracket (RH)- 1-¼"- UFF 50
2 8121524 Drain Pipe, Left Side (Use 823-3418 for Chili’s)
3 8130784 Drain Pipe, Right Side 1 ½” x 6”
4 8130829 Elbow, 1-½" NPT 75°
5 8130748 Tee, 1-½” NPT x 1-¼" BM With Handle Bracket
6 2001827 Drain Manifold Tube- 1-½” x 13-¼"
7 8130659 Pipe Cap, 1-½"
8 8090884 Nut, Slip Joint- 1-½"
* 8160544 O-ring (Slip-Joint Nut)
9 8130686 Bell Reducer, ½" NPT x 1-½"
10 8130165 Elbow, Street- ½" NPT 90°
11 8130672 Nipple, ½” NPT x 8" BM
12 8101669 Adapter, ⅝" O.D. x ½"- Female
13 8101069 Flex Line, ⅝" x 29-½ "
14 8101668 Adapter, ⅝" O.D. x ½"- Male
Drain Valve Components
15 1061401 Bracket, Microswitch (Optional On SUFF/UFF Units)
16 2001617 Washer, Drain Valve (Use Without Microswitch)
17 2102029 Bracket, Activator- Microswitch (Also Used On Valves Without Microswitch As A
Handle-Stop)
18 2104727 Handle (Actuator), Drain Valve
* 8233440 Handle, Push/Pull- Drain (With Cap)
* 8090885 Washer, ⅜” x 1” x .083"
* 8090843 Pin, Cotter
* 8160547 Cap, Vinyl-Red
19 8072104 Microswitch (Optional On SUFF/UFF Units)
20 8090842 Nut, Nylock- #4-40 (Microswitch To Bracket)
21 8160220 Insulation, Microswitch
22 2001257 Retainer, Nut
23 8102127 Drain Valve, 1-½" Full Port (With Washers & Nut)
24 8102052 Drain Valve, 1-¼" (1" Standard Port)
* 8102442 Handle, Valve Lever
* 8101338 Drain Valve, 1" SM20G, SR42G, ESG35T see note below
* 2103902 Handle, Valve Lever (For 8101338 Only)- SM20G
* 1061417SP Drain Valve Assembly 1” RH and LH
* 8130138 Nipple, 1" NPT x Close (To Adapt To 1-¼" Extended Drain Nipple)
* 8130716 Bushing, 1" NPT x 1-¼" BM (To Adapt To 1-¼" Extended Drain Nipple)
* 8130406 Coupling, 1-¼" NPT x 2" (To Adapt To 1-¼" Extended Drain Nipple)
25 8102126 Drain Valve, 1-¼" Full-Port (Use 106-2439 for Assembly)
* 8121226SP Nipple, Drain- 1-¼" Painted- SM Series Fryers (use 8130276 for SM20)
* 8130392 Nipple, Drain- 1-¼” NPT x 8" BM- All SR Series Fryers except SR42 w/ 1”
* 8121681 Nipple, Drain- 1-¼” x 5” NPT
* 8130870 Nipple, Drain- 1-¼” x 10” NPT
* 8130669 Nipple, Drain- 1” x 8” (Use 8121668 for 5”-SR42) (Use 8130605 for 9”- SR62)
* Not Illustrated
Note: In Mar. 2003 SR42G went to 1” drain valves.
