FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-3
2.1 Cabinetry Components, Single Fryers (cont.)
ITEM PART # COMPONENT
* 2103419 Top Cap (Front Canopy)- SM50GDD
* 2102821 Top Cap (Front Canopy)- SM60G, SR62G
* 2102811 Top Cap (Front Canopy)- SM80G
19 2601342 Flue Cap- SR42G, ESG35T, SR52G (Sep. 2005 to Current)
* 8234175 Flue Cap- SR42G, SR52G (Feb. 2003 – August 2005 ) obsolete
* 8234437 Flue Cap- SR62G
* 8233467 Flue Cap- SM35G, SM40G (SR42G, SR52G Prior To Feb. 2003) obsolete
* 8233700 Flue Cap- SM20G
* 8233702 Flue Cap- SM220G
* 8233521 Flue Cap- SM50G
* 8233575 Flue Cap- SM50GDD
* 8233635 Flue Cap- SM60G
* 8233512 Flue Cap- SM80G
20 2401344 Back, One-Piece Cabinet- SR42G, ESG35T, SR52G, SM50G (after July 2010)
* 2001377 Back, One-Piece Cabinet- SM35G, SM50G (before July 2010)
* 2001123 Back, Upper Cabinet- SR42G, SR52G, SM35G, SM50G
* 2001674 Back, Upper Cabinet- SM50G (SUFF), SM220G
* 2001213 Back, Upper Cabinet- SM60G / SR62G
* 2002683 Back, Upper Cabinet- SM80G
21 2001126 Back, Lower Cabinet- SM35G, SM50G, SM50GDD
* 2001327 Back, Lower Cabinet- SM60G
* 2102684 Back, Lower Cabinet- SM80G
Door Assembly Components
22 2003807 Panel, Inner Door- SM20G
* 2001379 Panel, Inner Door- SM220G, SM35G, SM40G, SM50G
* 2001185 Panel, Inner Door- SM60G
* 2002688 Panel, Inner Door- SM80G
23 1203082 Panel, Door- SR38G obsolete
* 2105241 Panel, Door- SR42G, ESG35T, SR52G (Assembly 1063150SP)
* 2105642 Panel, Door- SR62G (Assembly 1063444SP)
* 1064728 Door Assembly, Right with Liner- SM50
* 2103805 Panel, Outer Door- SM20G (Assembly 106-2482SP)
* 2102869 Panel, Outer Door- SM220G, SM35G, SM40G, SM50G (Assembly 1061754SP)
* 2101424 Panel, Outer Door- SM60G
* 2101151 Panel, Outer Door- SM80G (Assembly 1061698SP)
24 2001301 Pin, Door- All Millivolt Fryers (Use 8261343 for Springs qty. 10)
* 1061698SP Pin, Door Assembly- All Millivolt Fryers (short)
25 8090413 Spacer, Nylon- All Millivolt Fryers
26 2001307 Hinge, Door- Lower- All SR Series Fryers
* 2001675 Hinge, Door- Lower- All SM Series Fryers
27 8100180 Handle, Door- Chrome- All SM Series Fryers
* 8090918 Screw, #10-24 x ½" (Use With 8102105)
* 8090191 Washer, Lock ¼" (Use With 8102105)
* 8101422 Handle, Wireform- Door- SR42G, SR52G (Use 8102030 before Jan. 03)
* 8261379 Screw, #10 x ½" Round Phillips (Qty: 10) (Use With 810-1422)
28 8100066 Catch, Magnetic Door- All Millivolt Fryers
* 8233225 Splash Guard 42’s & 50’s (Use 8234767 for 60’s & 80’s)
* 2003663 Striker Plate all models except SR42
* 2102897 Striker Plate SR42
* 8030197 Fryers Friend Cleanout Tool
* Not Illustrated
