FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-7
2.3 Component Box Components and Related Components (CE and
Domestic- cont.)
ITEM PART # COMPONENT
1 8262013 Thermostat, Sunne (Use 8071692 for CE)
* 8102047 Spring, Spacer- Thermostat Capillary Bulb
* 2101302 Clamp, Thermostat/High Limit Capillary Bulb (Use 2101433 for 2 hole)
* 2001320 Mounting Bracket, Thermostat & High-Limit
2 8102035 Knob, Thermostat (Use 8160139 for CE)
3 2001618 Box, Thermostat- Single
4 2003217 Cover, Thermostat Box- Single
5 2003277 Box, Thermostat- Dual (Used in 20/50 Combination Systems)
6 2003906 Cover, Thermostat Box- Dual (Used in 20/50 Combination Systems)
7 8102033 Thermopile (Use 8073565 for CE)
8 8101152 Thermocouple (CE ONLY) (Use 8121284 for Assembly)
9 1061768SP ECO Connector (Honeywell Valves Only- CE ONLY)
* 1061879 ECO Connector (Robertshaw Valves Only- CE ONLY)
10 2005479 Bracket, Pilot Thermocouple
11 8102401 Bracket, Thermopile
12 8101001 Piezo Ignitor (Trigger) (Wire Lead-8073650) (Assembly-44970SP)
* 2001868 Piezo Bracket
* 8073540 Electrode, Piezo CE (Use 8121532 for modified Electrode)
13 8071999 Transformer, Dual Voltage CE- Filtration System (CE ONLY)
* 8070800 Transformer, 120/24 VAC- Filtration System
14 8073580 Switch, Rocker- Manual Filter Power
15 2102786 Guard, Switch (Optional- For Item 10)
16 8073516 High-Limit Thermostat- Automatic Reset 435° F SM20/35,SR40/42
* 8073560 High-Limit Thermostat- Manual Reset 410° F (CE)
* 8073680 High-Limit Thermostat- Manual Reset 450° F
* 8102046 Spring, Spacer- High Limit Capillary Bulb
17 8071321 Fuse Holder, Buss
* 2747 Fuse Holder, Slot-head—Safety (CE ONLY) (obsolete)
* 8073592 Fuse 2A Slow-Blow (230V Systems)
* 8073750 Fuse 5A (120V Systems)
* Not Illustrated
