FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-9
2.4.1 SM220 and SM20/20/~ Systems (cont.)
ITEM PART # COMPONENT
2 8130003 Tee, ½" NPT BM
3 8130087 Nipple, ½" NPT x 1-½" BM
4 8130173 Union, ½" NPT BM
5 8130780 Bushing, ⅜" NPT x ½" BM
6 8130631 Elbow, ⅜" NPT 90° BM
7 8130676 Nipple, ⅜" NPT x 2" BM
8 8130625 Nipple, ⅜" NPT x Close BM
9 8130649 Nipple, ⅜" NPT x 2-½" BM
10 8102352 Manifold, Gas- SM20G
* 2001615 Bracket, Manifold Mounting
11 8102050 Orifice, Natural- #44 (2.18 mm)- Domestic/International
* 8100710 Orifice, LP- #54 (1.40 mm)- Domestic/International
* 8102060 Orifice, G20-G25- (2.40 mm)- CE Only
* 8102059 Orifice, G31- (1.51 mm)- CE Only
12 8102151 Burner, Left
13 8102150 Burner, Right
* 2001374 Bracket, Burner Mounting- SM20G
* 2401391 Bracket, Burner Mounting- SM/D20G CE
* 2001331 Shield, Burner Heat- SM20G
14 8130668 Nipple, ⅜" NPT x 7" BM
15 8130782 Nipple, ⅜" NPT x 5" BM
16 8130781 Union, ⅜" NPT BM
17 8073645 Valve, Gas- Natural (Robertshaw MV) ½” in x ¾” out
* 8071603 Valve, Gas- Natural Honeywell ½” in x ½” out
* 8102036 Valve, Gas- Natural Honeywell ½” in x ¾” out
* 8072122 Valve, Gas- Natural CE Honeywell
* 8102399 Valve, Gas- Propane (Robertshaw MV)
* 8071604 Valve, Gas- Propane Honeywell
* 8072121 Valve, Gas- Propane CE Honeywell
* 8100975 Knob, Gas Valve Honeywell
* 8100691 Vent Tube 4” (Use 810-1166 for CE 3.86”)
18 8261874 Frypot Assembly- SM20G- M/S obsolete use 8261875
* 8261875 Frypot Assembly- SM20G- S/S
19 2005175 Diffuser, Burner-Tube- SM20G
20 8102158 Pilot Burner- SM20G- Natural(0.18 Orifice) (Use 8102526 for LP)
* 8102689 Pilot Assembly Honeywell w/ Piezo- Natural (Use 8102690 for LP)
* 1064968 Pilot Assembly w/ Piezo-Natural SM20G
* 1086842 Pilot Assembly w/ Piezo-Natural (0.18 Orifice) SM/D20G CE
21 8100703 Gas Line, Pilot Supply- ¼” x 17-½" (CE -810-1172 - ¼” x 22”)
* 8102602 Gas Line, Pilot Supply- ¼” x 25"
22 1061583SP
Flue Assembly- SM20G
* 2001342 Shield, Flue Heat- SM20G
* 2001344 Front, Flue Box- SM20G
* 2001351 Rear, Flue Box- SM20G
* 2003081 Air Shutter (Use KIT00092SP for Air Shutter Kit)
* Not Illustrated
SM 20 series began using Honeywell gas valves in July 2003.
