Frymaster Dean Super Runner Series - Page 36

FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-14
2.4.3 SR62, SM60G and SM80G Systems (cont.)
ITEM PART # COMPONENT
1 8233494SP Frypot- S/S- SM80G (After 10/99) 1¼” (Use 8233396SP for 1 ½”)
* 8261891 Frypot- S/S- SM80G (Prior To 10/99)
* 8261802 Frypot- S/S- SM60G (Use 8233511SP for SM160G)
* 8236063SP Frypot- S/S- SR62G
2 8233404 Diffuser, Burner Tube- SM80G
* 2105215 Diffuser, Burner Tube- SM60G, SR62G
3 8102150 Burner, Right- SM60G, SM80G, SR62G
4 8102149 Burner, Center- SM60G, SM80G, SR62G
5 8102151 Burner, Left- SM60G, SM80G, SR62G
* 2002734 Bracket, Burner Mounting- SM80G
* 2002738 Bracket, Burner Mounting- SM60G, SR62G
* 2002707 Shield, Burner Heat- SM80G
* 2002746 Shield, Burner Heat- SM60G, SR62G
6 2001314 Bracket, Manifold Mounting- SM80G
* 2001615 Bracket, Manifold Mounting- SM60G, SR62G
7 8090428 Bolt, ¼”-20 x ½" Hex Head
8 8090823 Nut, Nylock- ¼”-20
9 8102138 Valve, Trailing Pilot- SM60G, SM80G, SR62G adjustment valve
10 8130642 Tee, ⅛” NPT
11 8130705 Plug, Brass- ⅛” Square Head
12 8130643 Nipple, ⅛" NPT x Close BM
13
Orifice- Domestic/International
* 8102062 Orifice, Natural- #38 (2.58 mm)- SM80G
* 8102048 Orifice, Natural- #39 (2.53 mm)- SM60G, SR62G
* 8102063 Orifice, LP- #52 (1.61 mm)- SM80G, SR62G (Australia)
* 8102059 Orifice, LP- #53 (1.51 mm)- SM60G, SR62G
*
Orifice- CE Only
* 8102060 Orifice, G20-G25- (2.40 mm)- All Millivolt Fryers in This Section
* 8102059 Orifice, G31- (1.51 mm)- All Millivolt Fryers in This Section
14 8233617 Manifold, Gas- SM60G, SM80G, SR62G
15 8102036 Valve, Gas- Natural, Honeywell- Domestic/Intl ½” in x ¾” out
* 8072122 Valve, Gas- Natural, Honeywell- CE Only
* 8073648 Valve, Gas- Natural and MFG, Honeywell ¾” in x ¾” out (Export)
* 8073645 Valve, Gas- Natural, Robertshaw MV ½” in x ¾” out
* 8073549 Valve, Gas- LP, Honeywell- Domestic/Intl
* 8072121 Valve, Gas- LP, Honeywell- CE Only
* 8102399 Valve, Gas- LP, Robertshaw MV
16 8130174 Union- ¾" NPT BM
17 8130635 Nipple, ¾" NPT x 2-½" BM
18 8130066 Elbow- ¾" NPT 90° BM
19 8130743 Nipple, ¾" NPT x 3-½" BM
20 8130165 Elbow, Street- ½" NPT 90° BM
21 8130670 Nipple, ½" NPT x 19" BM (Measure To Confirm Length)
* 8130585 Nipple, ½" NPT x 20-½" BM (Measure To Confirm Length)
* 8130737 Nipple, ½" NPT x 21" BM (Measure To Confirm Length)
* Not Illustrated
