FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-19
2.5.2 3” Oil Drain Manifold, Drain Flush & Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 8234712 Tube, 3” Oval Dump
2 8234681 Tube, 3” Right Drain (closed end)
3 8234682 Tube, 3” Center Drain (open ends)
4 8234844 Tube, 3” Left Drain (closed end)
5 8235188 Tube, 3” Right Filter (open ends)
6 2006603 Tube, 3” Joiner (11.5”)
7 2009365 Tube, 3” Joiner (8.63”)
8 8090969 Clamp, T-bolt
9 8160625 Boot/Sleeve
1061726
Flush Oil Drain Line
10 8101669 Adapter, Female ⅝” O.D. x ½” long
11 8101668 Adapter, Male ⅝” O.D. x ½” long
12 8101056 Flexline, ⅝” O.D. x 52.5” long
1063976
Drain Valve Assembly, 1½” Without Microswitch
1063977
Drain Valve Assembly, 1½” With Microswitch
13 8102783 Drain Valve, 1½” Full Port with O-ring
14 8234734 Handle, Drain Valve Rotating
15 8072104 Microswitch, CE Micro-roller Lever
16 1061401 Microswitch Bracket Assembly
17 2004402 Guard, Drain Microswitch
18 8160220 Insulation, RF Switch
19 8160547 Cap, Red Vinyl for Handle
20 2006116 Strap, 1½” (holds tube to valve via the stud)
21 2001617 Washer, Drain Microswitch
22 2001257 Retainer, Drain Valve
23 8261366 Nut, 4-40 Keps Hex w/ External Teeth (Pkg. of 25)
* 8160630 Cap, Vinyl (one per clamp, covers T-bolt threads)
* Not Illustrated
