FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-26
2.7.2 Oil Return and Oil Flush Components; Fryers with 3” Drains (cont.)
ITEM PART # COMPONENT
1064006
Microswitch Bracket Assembly, Oil Return
1 9012772 Handle, RF Left
2 9002935 Retainer, Nut
3 8160220 Insulation, RF Switch
4 8100278 Ball Valve, ½” Oil Return
5 8261366 Nut, 4-40 Keps hex w/ External Teeth (Pkg. of 25)
6 8072103 Microswitch, Straight Lever (CE)
7 2006806 Cover, Safety Switch
8 1063962 Bracket Assembly, RF Switch
1061225
Oil Suction Assembly
9 8130062 Elbow, 90º BM
10 8130173 Union, ½” NPT 150# BM
11 8130654 Nipple, TBE ½” NPT x 4” BM
12 8130674 Nipple, TBE ½” NPT x 7.25” BM
13 2001230 Bracket, Front male Manifold
1060774
Suction Manifold Assembly
14 8100697 Disconnect, Male Suction Tube
15 8130608 Coupling, ½” NPT BM Full
16 8233188 Suction Manifold
1060858
Oil Suction Start Fitting
17 8130022 Nipple, ½” NPT Close
18 8130463 Plug, ½” Counter Sink
19 8130003 Tee, ½” NPT BM
* 2108790 Bracket, Oil Return/ Flush Retainer
* 2008929 Handle, Oil Return
* 2009850 Handle, Oil Return (Application Series “DF” Fryers)
* 8160548 Cap, Oil Return Handle, Yellow
* 8160549 Cap, Oil Return Handle, Blue
20 8102097 Motor/Pump Combo, 120-230V
* Not Illustrated
