Faxing (DocuPrint M215 fw Only)
276
1
Plug one end of a telephone line cord to the wall jack connector and the other end to an active
wall jack.
NOTE:
• Use the telephone line cord which has four contacts. The cord included with your printer has four contacts. It is
recommended that you plug the cord to the wall jack which also has four contacts.
2
To connect a telephone and/or answering machine to your printer, plug the telephone or
answering machine line cord into the phone connector ( ).
Wall jack connector
To the wall jack
Phone connector
To an external telephone
or answering machine
Ferrite core
(ivory)
Connector to be connected into
the PHONE port of the printer
Wind the cable twice around the ferrite core tightly.
Be careful not to pinch the cable when closing the core.
Wind twice
Approx. 7 cm
To Next Page
