Fuji Xerox DocuPrint M215 fw User Manual

83 Printer Connection and Software Installation
 Printing and Checking the System Settings Page
Print the System Settings page and check your printer's IP address.
This section includes:
• "The Operator Panel" on page 83
• "The Printer Setting Utility" on page 83
The Operator Panel
NOTE:
• The reports and lists are all printed in English.
1 Press the System button.
2 Select Report / List, and then press the button.
3 Select System Settings, and then press the button.
The System Settings page is printed.
4 Confirm the IP address next to IP Address under Wired Network/Wireless Network on the
System Settings page. If the IP address is 0.0.0.0, wait for a few minutes to resolve the IP
address automatically, and then print the System Settings page again.
If the IP address is not resolved automatically, see "Assigning an IP Address (for IPv4 Mode)" on
page 79.
The Printer Setting Utility
The following procedure uses Windows 7 as an example.
NOTE:
• The reports and lists are all printed in English.
1 Click start → All Programs → Fuji Xerox → Fuji Xerox Printer Software for Asia-Pacific →
your printer
→ Printer Setting Utility.
NOTE:
• The window to select a printer appears in this step, when multiple print drivers are installed on your
computer. In this case, click the name of the desired printer listed in
Printer Name .
The Printer Setting Utility appears.
2 Click the Printer Settings Report tab.
3 Select Reports from the list at the left side of the page.
The Reports page is displayed.
4 Click the System Settings button.
The System Settings page is printed.
If the IP address is 0.0.0.0 (the factory default) or 169.254.xx.xx, an IP address has not been
assigned.
See also:
• "Assigning an IP Address (for IPv4 Mode)" on page 79

Fuji Xerox DocuPrint M215 fw Specifications

General

Brand	Fuji Xerox
Model	DocuPrint M215 fw
Category	All in One Printer
Language	English
