Control Panel
69
Product Overview
2
7 <Interrupt> button Press this button to suspend a copy or print job in progress to have the
machine process another job. During the Interrupt mode, the <Interrupt>
button lights up. Pressing the <Interrupt> button again exits the Interrupt
mode and resumes the suspended job.
For notes and restrictions on the Interrupt mode, refer to "15 Appendix" > "Notes and
Restrictions" > "Notes and Restrictions on the Interrupt Mode" in the Administrator Guide.
8 <Stop> button Press this button to pause the current job or communications.
9 Push-button power switch Switches the power of the machine on and off.
Note •If the main power is not switched on, the machine will not be powered on
even when the power is switched on. For more information, refer to
"Power Source" (P.63).
10 <Start> button Press this button to start scanning a document.
11 <Error> indicator Blinks if a system error occurs.
This indicator lights up when a problem other than a system error occurs
with the machine, including paper jams and running out of paper or toner.
If the <Error> indicator blinks, contact our Customer Support Center.
If the <Error> indicator lights up, refer to "14 Problem Solving" > "Machine Trouble" in the
Administrator Guide.
12 <Data> indicator Blinks when the machine is sending or receiving data to or from a client.
This indicator lights up when data is stored in the machine's memory, when
received faxes are waiting to be printed, or when faxes are stored in a folder.
You can check stored scan files in a Folder List. For information on the Folder List, refer to "4
Machine Status" > "Machine Information" > "Print Reports" > "Folder List" in the
Administrator Guide.
You can check stored fax files in a Stored File List. For information on the Stored File List, refer
to "4 Machine Status" > "Machine Information" > "Print Reports" > "Job Status/Activity
Report" > "Stored File List" in the Administrator Guide.
You can change the lighting pattern of the <Data> indicator. For more information, refer to
"5 Tools" > "Common Service Settings" > "Other Settings" > "Data Indicator" in the
Administrator Guide.
13 <Main Power> indicator Lights up when the main power is switched on.
Note •If the main power is not switched on, the machine will not be powered on
even when the power is switched on.
14 <Dial Pause> button Press this button to insert a pause into a destination number.
15 <Speed Dial> button Press this button to specify a recipient with an address number when
sending a fax or e-mail.
16 <C (Clear)> button Press this button to cancel a numerical value you have entered with the
numeric keypad.
17 Numeric keypad Use the numeric buttons on the keypad to enter the number of copies,
passcodes, and other numerical values.
18 <Services Home> button Press this button to display the Services Home screen.
You can change the services displayed on the Services Home screen. For more information,
refer to "1 Before Using the Machine" > "Customizing the Control Panel" > "Customizing the
Button Layout" > "Services Home" in the Administrator Guide.
19 <Custom Button 1> (Copy) "Copy" is assigned to this button by default.
Press this button to display the [Copy] screen.
For information on how to assign a service to the button, refer to "1 Before Using the
Machine" > "Customizing the Control Panel" > "Assigning Services to the Custom Buttons" in
the Administrator Guide.
No. Component Function
To Next Page
