1 = Kensington Lock
2=DCINjack
3 = Monitor port
4 = LAN port
5=USBport
6 = ExpressCard slot
7 = Built-in loud speakers
8 = Easy Launch key
9 = ON/OFF switch for the Notebook
10 = Touchpad
11 = Touchpad scroll bar
12 = Touchpad b uttons
13 = Status indicators
14 = Headphones/SPDIF port
15 = Microphone port/Line In
16 = ON/OFF switch, Wireless LAN
17 = USB ports
18 = CD/DVD drive
19 = Modem port
20 = Service compartment (hard disk, memory)
21 = Battery
22 = Battery release
Preparat
ion for use and operation
Please observe the safety information in the section "Important notes", Page 2.
You must c harge the battery and install the application program mes before you can work with
the notebook. The operating syste m and drivers required are preinstalled.
This chapter also describes the basics for operating your notebook.
10600790786, edition 1 English - 4
Preparation for use and op eratio n
