SCALEOVIEW H22-1W/Q22W-1
Installing an ergonomic video workstation
Before you set up your equipment, you should select a suitable position for working at the monitor.
Please observe the following advice when installing a video workstation.
1
1
2
1 = Windows
Avoid direct and reflected glare.
Avoid glare from electric
lighting.
2 = Approx. 90° and more
3 = Approx. 90°
Remember to maintain correct
posture.
30°
30°
65°
65°
0°
60°
1
22
1 = Bearing surface for palms
of hands
2 = Reaching area for
frequently used equipment
Position the keyboard where it
is easiest to reach.
Example layout of monitor,
keyboard and copy-holder
1 = Preferable viewing sector
2 = Permissible viewing sector
Position the monitor for
optimum viewing. The viewing
distance to the monitor should
be approximately 50 cm.
Keep ventilated areas clear.
i
Depending on the situation, the use of a swivel arm or wall bracket (VESA FPMPMI), are available
from specialised dealers, may be advisable. For this purpose the monitor base must be removed
beforehand as described in the "
Mounting and removing the monitor base" chapter.
A26361-K1213-Z120-1-7619, edition 1 9
