SCALEOVIEW H22-1W/Q22W-1
Removing monitor base
Before you can use a swivel arm or a wall bracket, you must remove the entire monitor base.
► Switch off the monitor and pull the power plug out of the power socket.
!
The display surface is susceptible to scratching!
► Lay the monitor on its face on a soft surface.
► Remove the cover (3) and disconnect all
cables.
► Remove the screws (1, 2, 3 and 4) under the
covers.
You can now mount a swivel arm or a wall bracket
as per VESA FPMPMI with 100 mm hole spacing.
For instructions on how to mount the swivel arm or
wall bracket, please see the documentation for the
swivel arm or wall bracket.
12
43
A26361-K1213-Z120-1-7619, edition 1 11
