Video (AV/CVBS):
Yellow (6)
Connection for AV video input signals
e.g. for DVD player, video recorder, film camera with video port or
gaming console
AUDIO (7)
red (right)
white (left)
e.g. for DVD player, video recorder, film camera with video port,
gaming console, HDTV decoder or HDTV video recorder
PC AUDIO IN (8) Connection for audio input signals (LINE IN)
e.g. for a PC
USB (10)
USB (13)
USB ports to the PC e.g. for mouse, keyboard, digital camera
► If necessary, insert one plug of each audio cable in the AUDIO IN (8) sockets on the monitor
and make sure they are properly engaged.
Green: loudspeakers/headphones (11)
Pink: microphone (9) and (12)
► If necessary, insert one plug of the USB cable in the USB port (10) on the monitor and make
sure it is properly engaged.
► Plug the power cable supplied into the power connector (1) of the monitor.
► Mount the cover over the connections.
A lock (Kensington Lock) can be mounted in the security slot (14) to protect the monitor
from theft. A Kensington Lock is not included in the consignment of the monitor.
i
Connecting cables to the computer
Information on the computer connections and interfaces is contained in the operating manual for your
computer.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is usually active.
i
► Connect the data cable to the (active) monitor port on the computer and secure the plug-in
connection by tightening the safety screws.
► Insert the other plug of the each audio cable in the audio ports of the computer.
► Insert the other plug of the USB cable into a USB port of the computer.
14 A26361-K1213-Z120-1-7619, edition 1
